NUTECH
PUMP & SHAFT
PACKING
Dixie Packing & Seal offers a wide range of high-quality braided packing solutions designed to address the diverse needs of your pump and shaft applications. Explore our extensive NUTECH brand packing options, and feel free to contact us for further information and personalized assistance to find the perfect solution for your requirements.
NUTECH PACKING PRODUCTS
Click any item to purchase online!
MADE IN USA
NUTECH A-1 Packing is a constructed square braid packing with Syntex Fiber with a high temperature lubricant and graphited. Soft and pliable for general service on pumps and valves. Temperature 500 deg F, pH 4-10, speed 1500 FPM, pressure to 300 PSI. Equal to Sepco #402 and Garlock #8909.
NUTECH A-1
MADE IN USA
NUTECH G-2 Packing is a non-abrasive packing of PTFE fibers that are graphite filled. Graphite lubrication provides a heat transfer media that makes this an excellent packing for shaft and rod service against water, steam, oil, solvent, acids and alkalies to 550 deg F. It can be used in all chemical applications with the exception of oleum fuming nitric acid, aqua regia, fluorine and other strong oxidizing agents. Equal to Sepco #ML-4002, Garlock #5100, Chesterton #1750. Most commonly known as GFO. pH 0-14, speed 4300 FPM, pressure to 300 PSI.
NUTECH G-2
MADE IN USA
NUTECH S-2 Packing is an environmental for many applications where asbestos has been traditionally specified, especially in water, steam condensate, solvents, petro fluids and acid media. NOT recommended for alkalies, strong acids, strong oxidizing fluids of stripping agents. Speeds to 2200 FPM, temperatures to 500 deg F. Manufactured from Synthetic fiber and PTFE suspensoid. Equal to Sepco #ML2225, Garlock #8922/5801, Chesterton #412-W. pH 0-12, pressure to 500 PSI.
NUTECH S-2
MADE IN USA
NUTECH T-1 Packing is pure PTFE fibers with PTFE dispersion. General valve, control valve, reciprocating rods, low-speed centrifugal shafts against the strongest chemicals, solvents and steam to 500 deg F. pH 0-14, pressure to 300 PSI pumps, and 2000 PSI in valves, speed 1000 FPM. Equal to Sepco #ML2254, Garlock #5888/PM-7, Chesterton #11724/324.
NUTECH T-1
MADE IN USA
NUTECH T-2 Packing is manufactured from 100% Teflon filament yarn with a Teflon suspensoid lubricant. For service on shaft speeds to 1500 FPM. Against all chemicals also for air and gas valves. Temperatures to 500 deg F. Equal to Sepco #ML2235, Garlock #5889/PM-8, Chesterton #328/1728.
NUTECH T-2
MADE IN USA
NUTECH G-1 is a low friction, universal packing for pumps and valves, self-lubricating fiber. Manufactured from 100% graphite which can be applied to virtually all pumps and valves. Packing will not harden or glaze over and can result in a maintenance saving many times in excess of the actual packing cost. Applications in air or oxygen up to 850 deg F, up to 1200 deg F in steam, shaft speeds to 4000 FPM. Manufacturers consider this packing a service equivalent to Chesterton 1/375, Garlock #200, Sepco #ML-4444. Pressure to 500 PSI on pumps and 2500 PSI on valves, pH 0-14, Interlock braid.
NUTECH G-1
MADE IN USA
NUTECH S-1 Packing is aramid fiber with an inert lubricant yarn which allows the packing to be used in higher pressured applications than normally tolerated by other types of braided packings. Because of the stee-like strength of this yarn, it can be employed as back-up rings with other types of packing to combine different features into a packing set. For service in rods, valves, expansion joints, against water, steam solvents, mild acids, alkalies, oil to 500 deg F. Equal to Sepco #ML4800, Garlock #5200/PM-5, Chesterton #1740. pH 3/11, speed 1900 FPM, pressure to 500 PSI.
NUTECH S-1
MADE IN USA
NUTECH S-3 Packing is non-asbestos, high pressure, high temperature steam valve packing for all ranges of steam valves to 1200 deg F, maximum pressure to 2500 PSI. For valves of steam turbines, and automatic tube blowers. Also high-temp, motor-actuated slide valves and general high pressure valving. Flexible and formable for easy installation. Equal to Chesterton #1800.
NUTECH S-3
MADE IN USA
NUTECH T-1 FDA Packing is a FDA approved, food grade, pure PTFE fibers with PTFE dispersion. General valve, control valve, reciprocating rods, low-speed centrifugal shafts against the strongest chemicals, solvents and steam to 500 deg F. pH 0-14, pressure to 300 PSI pumps, and 2000 PSI in valves, speed 1000 FPM. Equal to Sepco #ML2254, Garlock #5888/PM-7, Chesterton #11724/324.
NUTECH T-1 FDA
Double construction of Instalon is 100% virgin PTFE. Its core is PTFE in plastic resin form that squeezes in all directions to fill all voids. Its spiraled covering is a PTFE tape molecularly oriented to resist extrusion. This double construction enables Instalon to conform to uneven flange surfaces. It is not affected by chemicals (except molten alkali metals)...never hardens...never adheres...completely inert.
Instalon Valve Stem Packing
Aramids/Meta-Aramids
300SA Slurry Pump Moderate Service Packing
310 Pulp and Paper Packing
Carbon/Graphite
4000 Pulp or Paper Production Packing
4000G Petrochemical or Refinery Packing
5000 High Temperature General Service Packing
5000-OCCHigh Temperature Moderate Abrasive Packing
5000C/CC Reinforced High Temperature General Service Packing
5000T General Service Packing
8000 Nuclear Packing
8000LC Extreme Service Non-Nuclear Packing
8500 Premium Grade Carbon Packing
Metal
8010 Lead Foil Packing
8011 Aluminum Foil Packing
8012 Lead Foil Packing Without Core
8013 Aluminum Foil Packing Without Core
895 Copper Anti-Extrusion Packing
Valve Stem
5000I High Temperature Valve Packing
5000IJ Ultra Low Emission Valve Packing
Phenolic
320 Pulp and Paper Packing
PTFE
344-SC Gate Valve Packing
344BILExtreme Chemical Pump Packing
344BIL-SC Extreme Chemical Pump Packing
344T Extreme Chemical Pump Gasket Tape
359 Marine Tanks, Latches, and Lids
360 Food or Pharmaceutical Packing
8000T-SC Gore "GFO" Gate Valve Packing
8100BIL High Strength PTFE/Graphite Packing
8200BIL Economic PTFE/Graphite Packing
Vegetable Fiber
345 Marine Tank, Latch, and Lid Packing
921 Marine Packing
921G Marine Packing
Aramid Corner Reinforced
3000T-K General Service Moderate Abrasive Resistant Packing
8000T-K PTFE/Graphite Abrasive Resistant Packing
8100BIL-K PTFE/Graphite Severe Abrasive Resistant Packing
